ابعاد

220 × 100 × 50 میلی متر

وزن

1000 گرم

منبع تغذیه

باتری

Sample Rate Range

250MSa/s(Single-channel)
125MSa/s(Dual-channel)

Waveform Interpolatio

(sin x)/x

Record Length

Max. 6K for single-channel; 3K samples per dual-channel

SEC/DIV Range

5ns/div~500s/div 1
2
5 sequence

A/D Converter

8-bit resolution
each channel sampled simultaneously

Low Frequency Response (-3db)

10Hz at BNC

Rise Time at BNC, typical

5ns

DC Gain Accuracy

?3% for Normal or Average acquisition mode
10V/div to 10mV/div

Note

Bandwidth reduced to 6MHz when using a 1X probe

Mode

Auto
Normal
single

Level

?4 divisions from center of scree

Slope

Rising
Falling
Rising & Falling

Source

CH1/CH2

Supported Probe Attenuation Factors

1X
10X
100X
1000X

Maximum Input Voltage

150VRMS
