مشخصات فنی

Mutual Capacitance: 5.6nF/100m nominal
Characteristic Impedance: 100Ω ?15%,1-600MHz
Nominal Velocity of Propagation: 69%
(Operating Temperature: -20 -60 (-4 -140
(Storage Temperature: -20 -80 (-4 -176
مشخصات کابل :
Conductor: 24 AWG(7/0.203 ?0.007mm), Multi-cores ( 7 cores at the least) Conductor Metal: Bare Copper
Insulation Material: HD-PE
OD: 1.10 ?0.05mm
Average Thickness: 0.25 mm
Outside-Tape Metal: MYLAR
Overlap Rate: 25%
(Drain Wire: 26 AWG(7/0.160 ?0.007mm
(Jacket hardness: 45P (90A ? 2A, Shore
Material: PVC UL94V-0 OD: 7.0mm ?0.2
Average Thickness: 0.60 mm
Color: Cool Gray 5C
Length type: 3000mm ? 30mm
کاربرد :
(10BASE-T, 100BASE-TX Fast Ethernet, 1000BASE-T, 10GBASE-T (IEEE802.3
100VG-AnyLAN (IEEE802.12) 550 MHz Broadband Video
Voice, T1, ISDN
155/ × 622 Mbps ATM
(Power over Ethernet (POE

AWG (ضخامت کابل)

24AWG

طبقه بندی

Cat 6
